Near Side Head Chipbreaker And Extraction Hood

Where available, we have listed below the most common spare parts for your machine to order directly from this page.

If the part you require is not listed below, please open a copy of the Wadkin GC Manual, note the page and reference number of the part your require, and complete the form below.

Also please indicated the Machine Test And Serial Number where ever possible.

Regards the "Wadkin Bursgreen Spares Team"

View Exploded Diagram

Drawing Ref	Part Number	Description	Price	Add to Basket
1	GA347	Spring Clip for Head Covers on Wadkin Moulders	£12.50
2	GA345	M16 Shoulder Pin for Wadkin GC300	£33.00
3	GA346	M20 Spacer for Wadkin GC300	£18.00
4	GA136	Top Cover for Near Side Head Hood for Wadkin GC300	P.O.A	—
5	GA1047	Exhaust Hood for Near Side Head for Wadkin GC300	£190.00
6	GA254	Post for Wadkin GC300	P.O.A	—
7	GA164	近侧头芯片偏转Wadkin GC300	£21.00
8	K0524103	Spring for Wadkin GC300	£26.00
9	K0525184	M8 x 10mm Long Hexagon Socket Capscrew for Wadkin GC300	P.O.A	—
10	K0525330	M8 x 10mm Long Hexagon Socket Countersunk Screw for Wadkin GC300	P.O.A	—
11	GA163	Pivot Pin for Near Side Head Chipbreaker for Wadkin GC300	£10.00
12	GA161	Near Side Head and Chipbreaker Shoe Pivot Pin for Wadkin GC300	£225.00
13	K0526126	M8 x 12mm Long Grub Screw for Wadkin GC300	P.O.A	—
14	K0527102	Hexagon nut M8 on Wadkin machines	£0.20
15	K0525520	Hexagon Head Setscrew M8 x 40mm Long for Wadkin WT Double Ender	£0.50
16	GA160	Near Side Head Chipbreaker Shoe for Wadkin GC300	£373.00
17	K0526269	Stud M10 x 60mm long for Wadkin machines	£3.00
18	K0528104	Plain washer M10 for Wadkin machine	£0.12
19	K3029903	Locking handle for Wadkin GC300	P.O.A	—
20	GA162	Adjusting Bar for Near Side Head Chipbraker for Wadkin GC300	£45.00
21	K0525530	Hex.Head Screw M10 x 25mm long	P.O.A	—
22	GA159	Shoe Chipbreaker Bracket On Wadkin GC4	P.O.A	—
23	GA1008	Side Cover for Near Side Head Hood for Wadkin GC300	P.O.A	—
24	K0526204	M6x 25mm Screwed Stud for Wadkin GC300	£1.00
25	K0528102	Washer M6	£0.25
26	K0527302	M6Wing Nut for Wadkin GC300	£0.25
